Traxxas TRX6 RC Hauler 1/10 Scale 6X6
Traxxas TRX6 RC Hauler 1/10 Scale 6X6 - Image 2
Traxxas TRX6 RC Hauler 1/10 Scale 6X6 - Image 3
Traxxas TRX6 RC Hauler 1/10 Scale 6X6 - Image 4
Traxxas TRX6 RC Hauler 1/10 Scale 6X6 - Image 5

Traxxas TRX6 RC Hauler 1/10 Scale 6X6

Original price was: ₹110,000.00.Current price is: ₹97,999.00.

Ready to order

💳 Payment Charges

  • Online Payment: 2% transaction charges
  • EMI Payment: 2.3% EMI charges

📦 EMI Offer (24 Months)

EMI starts from ₹4,177.21/month
(Includes 2.3% EMI processing fee)
DELIVERY CHECKCheck serviceability for your pincodeLive shipping availability
MACHINE OVERVIEWMachine Brief

Vehicle Specs

  • Length (overall): 37.5 inches (953 mm)
  • Length (chassis): 34.0 inches (863 mm)
  • Front Track: 9.8 inches (245 mm)
  • Rear Track: 9.8 inches (249 mm)
  • Ground Clearance: 3.14 inches (80 mm)
  • Weight: 10.7 pounds (4.83 kg)  Gross Wt: 6Kg
  • Box Size: 100 x 29.5 35cm
  • Height (overall): 11.9 inches (303 mm)
  • Wheelbase
  • (front & intermediate axle): 18.6 inches (471 mm)
  • Wheelbase
  • (front & rear most axle): 23.7 inches (603 mm)
  • Approach Angle: 60°
  • Departure Angle: 55°
  • Breakover Angle: 57°
  • Front Shock Length: 3.54 inches (90 mm)
  • Rear Shock Length: 3.54 inches (90 mm)
  • Front Wheels: 2.2 x 1.02 inches (56 x 26 mm)
  • Rear Wheels: 2.2 x 1.02 inches (56 x 26 mm)
  • Battery Tray: 158.75 L x 47 W x 23/26 mm H
  • Front Tyres: 4.64 x 1.89 inches (118 x 48 mm)
  • Rear Tyres: 4.64 x 1.89 inches (118 x 48 mm)
  • Hex Size: 12 mm
  • Speed Control: XL-5 HV
  • Motor (electric): Titan® 21T Reverse Rotation
  • Transmission: 2-speed High/Low, Remote Shifting
  • Gear Pitch: 32P
  • Differential Type: 4 Gear, Remote Locking
  • Chassis Structure / Material: Steel Ladder Frame with Nylon Composite Cross members
  • Brake Type: Electronic “Hill Hold”
  • Drive System: Shaft-Driven 6WD
  • Steering: Chassis Mounted Servo
  • Servo: 2075X Metal Gear
  • Transmitter: TQi™ 2.4GHz 4-Channel Transmitter
  • Receiver: 6533
  • Skill Level: 1



ESC Specs

  • Type: High-torque brushed motor
  • Size: 550
  • Weight: 390g (13.76oz)
  • Length: 3.071” (78mm) overall length, 2.25” (57mm) can length, 1.532” (38.9mm diameter)
  • Turns: 21T reverse rotation
  • Voltage: 16.8V

Motor

  • Input Voltage: 6–7 Cells NiMH, 2–3s LiPo
  • Case Size: 1.23” W x 2.18” D x 1.04” H
  • Weight: 2.6oz (74g)
  • Motor Limit: 21-turns (550 size)
  • On Resistance Forward: 0.004 Ohms
  • On Resistance Reverse: 0.004 Ohms
  • Peak Current – Forward: 100A
  • Peak Current – Reverse: 100A
  • Braking Current: 60A
  • Continuous Current: 18A
  • BEC Voltage: 6.0 VDC
  • BEC Current: 1A
  • Power Wire: 14 Gauge / 5”
  • Input Harness Wire: 26 Gauge / 14.5”
  • Transistor Type: MOSFET
  • PWM Frequency: 1700Hz
  • Low Voltage Detection (LVD): 2-Stage indicators, switchable (on or off)
  • Thermal Protection: Thermal Shutdown
  • Profile selection:
  • Sport Mode: 100% FWD, 100% brakes, 100% REV
  • Race Mode: 100% FWD, 100% brakes, no REV
  • Training Mode:* 50% FWD, 100% brakes, 50% REV
  • Trail Mode: 100% FWD, 100% Brake, 100% REV, Trail-Tuned Brake on Neutral
  • Crawl Mode: 100% FWD, 100% Instant REV, 100% Brake on Neutral
  • Single-button setup: Yes, Traxxas EZ-Set®
